Industrial door:it usually refers to the door used in factories and other industrial buildings for the passage of personnel or vehicles.Generally,the door leaf area and weight are larger and the safety requirements are higher.Installation method:the installation method of industrial door whose door leaf moves upward through guide rail.Sectional upturning type:the installation method of industrial door with straight door leaf upward through guide rail and sectional steering movement.Vertical lifting type:refers to the installation mode of industrial door whose door leaf moves vertically upward through navigation.Layered vertical lifting type:the installation mode of industrial doors in which several door leaves are stacked back and forth and move vertically up and down in layers through guide rails and transmission system.Conventional installation method:it refers to the installation method of sectional upturned industrial door,which can operate normally without special measures,and the transverse rails installed on the left and right sides are single.It is mainly applicable to openings with a lintel height of no less than 600mm.High lift type:refers to the installation mode of sectional upturned industrial door in which the door leaf runs vertically upward through the guide rail for a period and then turns in sections.Overhead installation mode:the installation mode of vertical lifting industrial door with torsion spring balance system on the top of fully open door leaf.Installation method of central beam:the installation method of vertical lifting industrial door with torsion spring balance system located in the central part of fully open door leaf.Counterweight balance mode:the installation mode of vertical lifting industrial door that uses counterweight to balance the weight of door leaf.Push-pull type:the installation mode of industrial door that pushes and pulls the door leaf to the left and right through the guide rail and transmission system.Upper bearing type:refers to the installation method of push-pull industrial door whose weight is borne by the guide rail at the top of the door leaf.Lower bearing type:refers to the installation method of push-pull industrial door whose weight is borne by the ground rail at the lower part of the door leaf.Fixed type of lower load-bearing motor:the installation method of lower load-bearing industrial door at the fixed position of straight door opener.Lower load-bearing motor follow-up type:refers to the installation mode of lower load-bearing industrial door in which the door opener is installed on the door leaf and moves with the door leaf.Push-pull folding type:refers to the installation mode of push-pull industrial door in which multiple shutter plates are connected through hinges and the leading door plate is gradually folded during the opening process.Side sliding type:refers to the installation mode of industrial door with the help of guide rail,the lifting wheel slides laterally along the wall and makes steering movement at one side of the door stack.Rolling shutter type:the installation mode of industrial door that drives the movement of curtain leaf through the rotation of reel or drum,so as to realize the opening and closing of door leaf.Whole plate industrial rolling shutter door:it is an industrial rolling door composed of high-strength color coated steel plate,torsion spring balance system and positive silencing system.Compared with rolling shutter garage door,the general door leaf has larger area and weight and higher safety requirements.Double layer curtain type industrial rolling door:refers to the industrial rolling door whose curtain type door leaf is made of aluminum alloy profile or steel profile and is internally filled with sound insulation and thermal insulation materials.2).special accessory buffer booster:a mechanism installed at the end of the guide rail to realize the buffer function when the door leaf is in place and the boost function when starting.Door in door(small door):refers to the small door opened in the door leaf of the gate in order to facilitate the passage of personnel in the larger industrial door.Daylighting window:a transparent window opened on the door leaf to enhance indoor light.Flat wheel:refers to the steel wire rope wheel with column shape and suitable for conventional installation and low altitude installation.Tower pulley:refers to the steel wire rope pulley which is shaped like a tower and suitable for vertical lifting industrial doors.Half tower wheel:refers to the steel wire rope wheel whose shape is part of column type and part of tower type,which is suitable for high-level lifting industrial door.Coupling:a structural member that connects the torsion spring shaft to realize synchronous rotation.Wire rope breaking protector:refers to the safety protection device that can quickly prevent the door leaf from sliding downward when the wire rope in the upper sliding door system is broken.Torsion spring anti fracture Protector:refers to a safety protection device that can quickly prevent the movement of torsion spring shaft and organize the door leaf to slide downward when the torsion spring in the upper sliding door balance system is broken.



　　工業門：通常指用于廠房和其他工業建筑場合，供人員或車輛通行的大門，一般門扇面積和重量較大，性要求更高。



　　Industrial door:it usually refers to the door used in factories and other industrial buildings for the passage of personnel or vehicles.Generally,the door leaf area and weight are larger and the safety requirements are higher.



　　安裝方式：門扇通過導軌向上運動的工業門的安裝方式。



　　Installation method:the installation method of industrial door whose door leaf moves upward through guide rail.



　　分節上翻式：直門扇通過導軌向上并有分段轉向運動的工業門的安裝方式。



　　Sectional upturning type:the installation method of industrial door with straight door leaf upward through guide rail and sectional steering movement.



　　垂直提升式：指門扇通過導航整體垂直向上運動的工業門的安裝方式。



　　Vertical lifting type:refers to the installation mode of industrial door whose door leaf moves vertically upward through navigation.



　　分層垂直提升式：若干塊門扇前后疊放，通過導軌和傳動系統使其分層次垂直上下運動的工業門的安裝方式。



　　Layered vertical lifting type:the installation mode of industrial doors in which several door leaves are stacked back and forth and move vertically up and down in layers through guide rails and transmission system.



　　常規安裝方式：指不需采取特殊措施，左右側安裝的橫軌均為單根即能正常運行的分節上翻式工業門的安裝方式，主要適用于門楣高度不小于600mm的洞口。



　　Conventional installation method:it refers to the installation method of sectional upturned industrial door,which can operate normally without special measures,and the transverse rails installed on the left and right sides are single.It is mainly applicable to openings with a lintel height of no less than 600mm.



　　高位提升式：指門扇通過導軌垂直向上運行一段后再分段轉向運動的分節上翻式工業門的安裝方式。



　　High lift type:refers to the installation mode of sectional upturned industrial door in which the door leaf runs vertically upward through the guide rail for a period and then turns in sections.



　　頂置安裝方式：扭簧平衡系統位于完全開啟的門扇頂部的垂直提升式工業門的安裝方式。中置粱安裝方式：扭簧平衡系統位于完全開啟的門扇的部位的垂直提升式工業門的安裝方式。



　　Overhead installation mode:the installation mode of vertical lifting industrial door with torsion spring balance system on the top of fully open door leaf.Installation method of central beam:the installation method of vertical lifting industrial door with torsion spring balance system located in the central part of fully open door leaf.



　　配重平衡方式：采用配重方式來平衡門扇重量的垂直提升式工業門的安裝方式。



　　Counterweight balance mode:the installation mode of vertical lifting industrial door that uses counterweight to balance the weight of door leaf.



　　推拉式：通過導軌和傳動系統使門扇向左右方向推拉的工業門的安裝方式。



　　Push-pull type:the installation mode of industrial door that pushes and pulls the door leaf to the left and right through the guide rail and transmission system.



　　上承重式：指門扇重量由門扇頂部導軌來承受的推拉式工業門的安裝方式。



　　Upper bearing type:refers to the installation method of push-pull industrial door whose weight is borne by the guide rail at the top of the door leaf.



　　下承重式：指門扇重量由門扇下部的地軌來承受的推拉式工業門的安裝方式。



　　Lower bearing type:refers to the installation method of push-pull industrial door whose weight is borne by the ground rail at the lower part of the door leaf.



　　下承重電機固定式：直開門機固定位置的下承重式工業門的安裝方式。



　　Fixed type of lower load-bearing motor:the installation method of lower load-bearing industrial door at the fixed position of straight door opener.



　　下承重電機隨動式：指開門機安裝在門扇上隨門扇運動的下承重式工業門的安裝方式。



　　Lower load-bearing motor follow-up type:refers to the installation mode of lower load-bearing industrial door in which the door opener is installed on the door leaf and moves with the door leaf.



　　推拉折疊式：指多快門板通過鉸鏈連接、開啟過程中相領門板逐步折疊起來的推拉式工業門的安裝方式。



　　Push-pull folding type:refers to the installation mode of push-pull industrial door in which multiple shutter plates are connected through hinges and the leading door plate is gradually folded during the opening process.



　　側滑式：指借助于導軌，吊輪沿墻面作側向滑移，并在一側門垛處作轉向運動的工業門的安裝方式。



　　Side sliding type:refers to the installation mode of industrial door with the help of guide rail,the lifting wheel slides laterally along the wall and makes steering movement at one side of the door stack.



　　卷簾式：通過卷軸或卷筒轉動帶動簾片式門扇運動、從而實現門扇啟閉的工業門的安裝方式。整板工業卷簾門：是有高強度彩涂鋼板扎制成型的整板門扇、扭簧平衡系統和導正消音系統等組合而成的工業卷門，相對卷簾式車庫門而言，一般門扇面積和重量較大，性要求更高。雙層簾片式工業卷門：指簾片式門扇是由鋁合金型材或鋼制型材，具內部填充隔聲、保溫材料制成的工業卷門。



　　Rolling shutter type:the installation mode of industrial door that drives the movement of curtain leaf through the rotation of reel or drum,so as to realize the opening and closing of door leaf.Whole plate industrial rolling shutter door:it is an industrial rolling door composed of high-strength color coated steel plate,torsion spring balance system and positive silencing system.Compared with rolling shutter garage door,the general door leaf has larger area and weight and higher safety requirements.Double layer curtain type industrial rolling door:refers to the industrial rolling door whose curtain type door leaf is made of aluminum alloy profile or steel profile and is internally filled with sound insulation and thermal insulation materials.



　　2）、專用配件



　　2).special accessories



　　緩沖助推器：安裝在導軌末端，實現門扇到位時的緩沖和啟動時的助推功能的機構。



　　Buffer booster:a mechanism installed at the end of the guide rail to realize the buffer function when the door leaf is in place and the boost function when starting.



　　門中門（小門）：指在較大的工業門中，為方便人員通行在大門門扇中開設的小門。



　　Door in door(small door):refers to the small door opened in the door leaf of the gate in order to facilitate the passage of personnel in the larger industrial door.



　　采光窗：為增強室內光線而在門扇上開設的透明窗戶。



　　Daylighting window:a transparent window opened on the door leaf to enhance indoor light.



　　平輪：指形狀為柱型，適于常規安裝方式和低空安裝方式用的鋼絲繩輪。



　　Flat wheel:refers to the steel wire rope wheel with column shape and suitable for conventional installation and low altitude installation.



　　塔輪：指形狀似塔型，適于垂直提升式工業門用的鋼絲繩輪。



　　Tower pulley:refers to the steel wire rope pulley which is shaped like a tower and suitable for vertical lifting industrial doors.



　　半塔輪：指形狀一部分為柱型、一部分為塔型，適于高位提升式工業門用的鋼絲繩輪。



　　Half tower wheel:refers to the steel wire rope wheel whose shape is part of column type and part of tower type,which is suitable for high-level lifting industrial door.



　　聯軸器：將的扭簧軸連接起來，實現同步轉動的結構件。



　　Coupling:a structural member that connects the torsion spring shaft to realize synchronous rotation.



　　鋼絲繩斷裂保護器：指在上滑道門系統中的鋼絲繩斷裂時，能迅速防止門扇向下滑行的保護裝置。



　　Wire rope breaking protector:refers to the safety protection device that can quickly prevent the door leaf from sliding downward when the wire rope in the upper sliding door system is broken.



　　扭簧防斷裂保護器：指在上滑道門平衡系統中的扭簧斷裂時，能迅速防止扭簧軸運動，實現組織門扇向下滑行的保護裝置。



　　Torsion spring anti fracture Protector:refers to a safety protection device that can quickly prevent the movement of torsion spring shaft and organize the door leaf to slide downward when the torsion spring in the upper sliding door balance system is broken.
